Gates MegaCrimp Male DIN 24 Cone Light Series 5/8in ID M30X2.0 Model G25615-1022

Gates MegaCrimp Hydraulic Coupling Male DIN 24 Cone Light Series, 5/8in I.D. - M30X2.0 Thread Gates MegaCrimp couplings are designed for use with Gates wire braid hydraulic hose to create a robust, leak-free assembly. The pre-assembled coupling is designed with a patented C insert attached to the ferrule. This design ensures that crimping forces are evenly distributed to form a concentric, leak-free seal. Features: * Robust bite-the-wire crimp. * Tested to an industry-leading 1 million impulse cycles * Simplifies inventory management * Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance SAE Standard * Popular thread styles also available with TuffCoat Xtreme plating for 583% higher corrosion resistance than SAE * Tested to industry-leading 600,000 impulse cycles * Simplifies inventory management * Environmentally-friendly TuffCoat plating for 345 percent better corrosion resistance than SAE standard Specifications: Outside Diameter: 22 MM Stem Hex Size: 32 MM Cut-Off Length: 1.27 IN Length: 2.75 IN Seal Type: Mated Angle w/O-Ring Termination: DIN O-Ring Location: On Female w/Inverted Nose Seat Seat Angle: 24 DIN Series: Light Gender: Male Bent Tube Angle: Straight Swivel: No Coupling Description: MegaCrimp Male DIN 24 Cone - Light Series Industrial Description: 10G-22MDL Thread Size: M30X2.0 Inside Diameter: .625 IN Hydraulic Hose Recommendation: Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose Inside Diameter: 15.9 MM Cut-Off Length: 32.3 MM Length: 69.8 MM Part Interchanges: NAPA G25615-1022 Recommendation: Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose. - Brand New Item - Part Number: G25615-1022 90 Day Warranty Included! ----------------------------------------------------- 1 Factory Radio is proud to introduce our line of liquidation listings! These are new items that are priced to move. Any cosmetic blemishes are noted in the condition field so please keep that in mind when purchasing. All items are guaranteed to be in 100% working order with our standard 30 day return and 90 day warranty so you’ll still be covered by our top-notch customer service. We’ll be adding new listings to this line every day at limited quantities so be sure to bookmark and keep watch for more great deals! ----------------------------------------------------- This is a Gates MegaCrimp Hydraulic Couplings Male DIN 24 Cone Light Series. This item is in NEW condition, with all items included unless otherwise listed. Please see photos for details. As you can see from our reviews, we package and ship everything very carefully. If you have any questions about any item listed, please do not hesitate to reach out. Thank You for Your Purchase!
